產品型號Name

單位Unit

CNGPZ25-4000-610-HXSA型

CNGPZ25-3000-559-HXSA型

CNGPZ25-1800-406-HXSA型

外徑OD

mm

610

559

406

最小壁厚Thickness(min)

mm

29.3

27

19.6

容器長度Lenght

mm

6100

6100

6100

容器數量Quantity

unit

3

3

3

工作壓力Working Pressure

Mpa

1-25

1-25

1-25

設計壓力Designed Pressure

Mpa

27.6

27.6

27.6

設計溫度Designed Temperature

.C

93

93

93

充裝介質Media filed in

CNG

CNG

CNG

水壓試驗壓力Hydrostatic Testing Pressure

Mpa

32.5

32.5

32.5

氣密試驗壓力Alright Testing Pressure

Mpa

27.6

27.6

27.6

單支水容積Water Volume Perunit

M3

1.33

1.1

0.6

總水容積Total Water Volume

M3

4

3.3

1.8

充裝總?cè)莘eTotal Volume

Nm3

1155

900

540

單量Unit Weight

kg

2906

2450

1271

總量Total weight

kg

10500

9000

4500

技術說明：1.容器按AMSE V1II-1/Q/HXSGWF01-2004<<固定氣高壓氣體無縫瓶式壓力容器>>進行設計、制造、檢測
Designing Manufacture and Examing to ASEM V1II-1/Q/HXSGWF01-2004 Bound High pressure Gas Cylinder Seamless Vessels

1. 容器材質為SA372Gr.J.CI.70? Material.SA372Grade.J.Class70
2. 可按客戶要求、制造其他規格的瓶式容器 Manufacturing the Vessels according to the?????? clients requirements
