2 OPERATING CONDITIONS :
Inlet gas temperature: Ambient temperature
Suction pressure: 1.4～2.5MPa(g)
Discharge pressure: 25MPa (g)
Capacity: 400～700Nm3/h
Low vibration, low noise, convenient for operation and maintenance, safe and reliable, highly efficient and energy saving.
|
2 Features :
High rigidity frame, reasonable internal rib configuration, detachable cylindrical type crosshead guide.
All driving parts are forged with high quality alloy steel.
Large capacity inter stage separator.
The unit is overall air-cooling, skid-mounted enclosure structure, easy to install.
With sound insulation enclosure of special design the external noise is lower than 76dBA.
PLC control system monitors the status, temperature and pressure of the unit so to realize automatic start-up and shutdown of the unit.
The unit is equipped with full safety devices. All electrical components are in conformity to the Ex-proof requirements of natural gas environment.
Gas valves and packing of international brands are adopted with reliable quality and long service life. |
|
