2 Main Technical Parameters
Nominal Pressure PN (MPa): 1.6～10
Nominal Diameter DN (mm):20～600
Working Temperature(℃):-20～60
Filter Precision(μm): 1～30
Initial Pressure Difference (MPa): ＜0.13
Replacing Pressure Difference (MPa):0.1
Filter Efficiency: Solid 99.98%
Liquid 99.5%
|
2 Features
1. It accords with the requirement of GB150-1998 “Steel pressure vessels”and “Supervision regulation on safety technology for pressure vessel”;
2. PCHG filtration aggregation core makes the filter precision no lower than 5μm; It also has features such as little pressure loss, compact structure and convenient installation.
3. It can be designed according to different requirements of the customers.
|
|
